The idea behind Black Bolt is to meet the needs of a very specific goal. Once a very specific goal is formed, a project can be tailored to fit exactly. In this space you can download the stl files for different bodies and different frames. The idea is that anyone can 3d print the best body for their application. Do you want different camera tilts, different electronics, a gopro mount? There can be a different body for every need.
This bulbous headed body is made for the standard XBR220 build. It's a good tilt for slower or even 3D flight. If hot gluing the cam in place there is room inside for some adjustment a few degrees up or down. Units in mm.
This is the standard body. Setup for 30 degrees of tilt for the standard XBR220 build. If hot gluing the cam there is a bit of wiggle room for a bit more or less tilt. Units in mm.
This body is for the fastest pilots who don't care that it will be hard to hover while staring at the sky. The cameras board sits right on the pdb so make sure there are no wires in the way. Units in mm.
This is the same body as the other 45° tilt with the exception of the pinched lines that give a touch of style. Units in mm.
This body was designed to use the slimmer HS1177m camera. Standard 30 degrees tilt. Units in mm.
This body uses the slimmer HS1177m camera. The tilt is all the way to 45 degree for the crazy pilot who wont be hovering. Recommend a wide lens. Units in mm.
